56uF400V 56uF400V --EngrWorld


Items	Characteristics
Category Temperature ange	-40 to +105oC
	6.3V to 100 Vdc
Rated Voltage Range
Capacitance Tolerance	±20% (M) (at 20oC ,120Hz)
Leakage Current	I≤0.01CV or 3μA , which is greater after application of rated Voltage for 2minutes

Dissipation Factor	Rated Voltage(V)	6.3V		10V	16V	25V	35V	50V	63V	100V	(at 20oC ,120Hz)


	tanδ(Max.)	0.22		0.19	0.16	0.14	0.12	0.1	0.08	0.08
	For capacitance>1000uF.and 2% per another 1000uF
Low Temperature Characteristics	Impedance ration max at 120Hz
	Working voltage	6.3v	10v	16v	25v	35v	50v	63V	100V
	Z-25℃/ Z+20℃	4	3	2	2	2	2	2	2
	Z-40℃/ Z+20℃	8	6	4	3	3	3	3	3

450V 10uF Aluminum Electrolytic Capacitor 10x20mm Through Hole 105C

Q: How about your after-sale service?
1. 365 day warranty
2. If the customer has any questions, we will provide technicalsupport timely.

Q: What are the advantages of your products?
1. We have all models of material, save you time looking fort And recommend materials for you if you need.
2. With the same quality products, we can give you best priceInquiries to after-sale, we will provide good service, such asupdate product status, technical support etc (24 hour online)
3. We have many stocks, and the delivery time usually is short.

Q: What is your MOQ?
A: No MOQ. we accept small orders. Because we believe thatsmall orders may become big orders in the future.

Q: If I place an order, how long will it take to deliver?
A: It usually takes about only 7-14 days after receiving thepayment, depends on the quantity ordered and the stock status.

	类型	描述
	产品类型	新型电解电容器
	制造商	JYH HSU(JEC)ELECTRON
	品牌	JEC
	原产地	Guangdong, China
	容差	10%
	电容	56uF
	工作温度	105°C
	电压 - 击穿	100
	尺寸	10*20MM
	封装/外壳	Metal
	应用	electronic product
	寿命	2000H
